HIGH QUALITY AND MODERN DESIGN
PRISMATIC
Classic form of the profile and high parameters in terms of thermal insulation.
In each system you will find
FIND YOUR
colour
* The offer includes a range of wood-like colors and the RAL palette. The colors shown are for reference only and may differ from the actual colors.
VISIBLY MORE
features
1.
WINSTEP PVC
AND ALU-PVC
A solution that makes it easier to go out onto the balcony and reduces the risk of tripping.
See more
3.
SLIDING
WINDOW
1.
DESIGN+
KEY LOCK HANDLE
2.
RC1 AND RC2
ANTI-BURGLARY FITTING
Increased burglary protection through mushroom striker plates, an anti-drill plate and key lock handle.
See more3.
TEMPERED AND ANTI-BURGLARY
GLASS PANELS
1.
REINFORCEMENT
The galvanised steel reinforcement ensures the durability, stability and functionality of the window.
2.
EPDM
GASKETS
Durable and flexible gaskets with high resistance to atmospheric conditions such as UV radiation, humidity or ambient temperature changes.
3.
WINKHAUS
PRO LIGHT FITTING
This excellent, advanced design guarantees the safety and comfort of use of our windows for many years.
See more1.
GLUED-ON
AND INTERNAL MUNTINS
2.
WINKHAUS
PRO LIGHT SELECT
Our completely invisible hinges, concealed between the frame and the sash, highlight the unique design of the window.
See more3.
EPDM
GASKETSGASKETS
Durable and flexible gasketsgaskets with high resistance to weather conditions, such as UV radiation, humidity or ambient temperature changes.
4.
WARMATEC GLASS
PANEL SPACER
Aesthetic and energy-saving spacer, available in 3 colours to perfectly match the colours of the window.
See more
6.
COLORFULL
The uniform colour and structure of the entire window - even when opened - will provide your windows with an exquisite character.
7.
ORNAMENTAL
GLASS PANELS
1.
WARMATEC
GLASS PANEL SPACER
Improved tightness of the glass panels and better thermal insulation ensure a comfortable temperature in the room.
See more2.
ENERGY, WARM AND COMFORT
SEALED GLAZING UNITS
3.
EPDM
GASKETS
Durable and flexible gaskets with high resistance to weather conditions improve thermal insulation and reduce heat loss.
1.
PSK
Balcony doors with an increased glazing area that lets more light into the house.
2.
WINSTEP PVC
AND ALU-PVC
Low balcony threshold making it easier to move between the interior and the terrace or balcony, reducing the risk of tripping.
See more3.
WIN CLICK
A handgrip for shutting the balcony door from the outside, without using the handle, so that you can easily go back inside.
See more
VISIBLY MORE
projects
VISIBLY MORE
details
Insulation
5-chamber class A window profile with 76 mm casing depth.
The window structure is a proprietary design of Oknoplast, based on top-quality class A window profiles. The number of chambers and the profile wall thickness guarantee not only the stability and durability of the window, but most importantly, ensure improved protection against low temperatures and noise. With a smaller sash dimension (112 mm casing), more daylight enters the room, which also reduces heating costs.
Two-chamber sealed glazing unit Ug=0,5W/m2K
This is possible to use in the PRISMATIC window two-chamber glazing units with a coefficient of Ug=0.5W/m2K. With this solution, the PRISMATIC window may be included in the energy-saving window segment (Uw of 0.78 W/m2K).
Uw=0,78 W/m2K
The lower the coefficient of UW thermal conductivity of a window, the less loss of energy and lower heating costs. ThePRISMATIC window with a Uw coefficient of 0.8 (with Ug=0.5 glazing unit and Warmatec frame) not only meets but also exceeds the rigorous standards for thermal insulation, ensuring the comfort of the homeowner.
A coloured Warmatec frame is available as an option
The Warmatec frame, made of high-grade stainless steel and plastic, is a combination of outstanding parameters with high aesthetic value. The frame minimises the risk of vapour condensation in the corners, which are the coldest points of the glass panel. It also improves the thermal performance of the window, thus reducing energy consumption costs (reduction of the U-value by as much as 10%). With the available selection of colours, the frame will give the window an air of elegance and will make it possible for the user to match it to the colour of the window.
Under-sill trim with gasket
The PRISMATIC window is fitted with an under-sill trim with gasket that enables correct and sealed assembly of the cillboard and the windowsill. The trim further improves the thermal and noise insulation of the window. A special gasket in the trim also provides additional protection against the penetration of rainwater into the room.
Sound Reduction Index (dB) = 34 (-1, -4)
The higher the Rw value of acoustic insulation of a window, the greater the protection against noise. The PRISMATIC profile, with an Rw (dB) = 34 (-1, -4) coefficient, is a barrier against annoying noises and provides peace and quiet.
Safety
The SafetyPlus mushroom striker plates are fastened to the steel reinforcement inside the frame
The SafetyPlus mushroom striker plates are fastened to the steel reinforcement inside the frame. The mushroom striker plates are attached to the steel reinforcement, which makes breaking into the room significantly more difficult. This solution provides additional protection against burglary.
1.75 mm thick window sash reinforcement
This proprietary profile reinforcement made of bent galvanised steel makes it possible to design large-sized windows. The thickness, shape and profile of the reinforcement ensure rigidity, correct function and an unchanged shape of the windows for many years. It also provides additional security for the window. The steel reinforcement system in the PRISMATIC sash is patent pending.
7-year warranty
The products are covered by 7-year warranty, which confirms both their quality and the professionalism of our company. The warranty is not subject to any restrictions, such as payable technical inspections.
Comfort
Winkhaus Prolight Select invisible hinges
The fitting makes the handling of the window sash easier and increases protection against uncontrolled slamming. Unique, patented "SAFE LOCATION" solution - a system of specially designed fitting elements that ensure the correct sash position in the window. Additional multi-step tilt regulation by the handle ensures even more convenient use of the window.
1.75 mm thick window sash reinforcement
This proprietary profile reinforcement made of bent galvanised steel makes it possible to design large-sized windows. The thickness, shape and profile of the reinforcement ensure rigidity, correct function and an unchanged shape of the windows for many years. It also provides additional security for the window. The steel reinforcement system in the PRISMATIC sash is patent pending.
7-year warranty
The products are covered by 7-year warranty, which confirms both their quality and the professionalism of our company. The warranty is not subject to any restrictions, such as payable technical inspections.
Microventillation
A window unsealing mechanism to let in fresh air without the need to tilt or open the window at all. The perfect solution when the temperature is above 0°C.
Window tilt restrictor
A mechanism in the tilt window preventing the sash from shutting on its own. This element provides protection against the slamming of the sash due to draft.
Optionally, the low win-step threshold can be used
This reliable balcony window element reduces the risk of tripping. Reducing the threshold height to 20 mm allows free movement between the flat and the terrace or balcony.
Appearance
Unique design
Proprietary, lean and more elegant profile. The larger glazing area compared to traditional profiles reduces the consumption of heating energy by increasing the volume of sunlight entering through the window.
Accessories
Unique glass gasket finishing solution at the angle of 45°; the glazing bead, harmonised with the sash curvature, and special drain plugs in Sheffield Oak colour improve the visual aesthetic of the window.
dESIGN+ handle
The dESIGN+ handle was designed in cooperation with the renowned design consultant KISKA, exclusively for the Oknoplast brand. The shape of the handle lends it a modern, minimalistic character. Furthermore, the handle is durable and comfortable to use, and its universal tint harmonises both with modern and classical interiors. Also available with a key lock.
EPDM gaskets
Durable and flexible gaskets with high resistance to weather conditions, such as UV radiation, humidity or ambient temperature changes.
